Droplet cleaning detection
Intelligent droplet cleaning detection technology ensures excellent arc start quality by monitoring and cleaning the welding wire tip before each arc initiation, reducing defects and improving consistency.
Full-Digital IGBT Inverter Multifunction Welding Machine
Ehave2 CM Series
The Megmeet Ehave2 CM Series is a versatile all-in-one welding solution supporting CO2/MAG, MIG, DC TIG, MMA, and Arc Gouging. With over 20 independent patented technologies, it delivers Class 1 energy efficiency and exceptional reliability for heavy industrial applications up to 630A.
All-in-one welding
Supports CO2/MAG, MIG, DC TIG, MMA, and Arc Gouging processes in a single machine, eliminating the need for multiple dedicated welding units.
Up to 630A output
Available in 350A, 500A, and 630A variants, all rated at 100% duty cycle for continuous heavy-duty industrial welding operations.
20+ patented technologies
Incorporates over 20 independent patented technologies including droplet cleaning detection, expert welding database, and intelligent closed-loop wire feeding.
Features & Enhancements
Expert welding database
The Multi-function (M) variant includes an expert welding database with 99 JOB parameter groups, allowing operators to quickly recall optimized settings for different materials and applications.
Long-cable compensation
Stable welding performance maintained even with cable extensions up to 50 meters, making it ideal for large-scale construction and shipbuilding applications where the power source cannot be positioned nearby.
Specifications & parameters
Rated output current350A
Rated output voltage31.5V
No-load voltage60V
Rated input power13.1KVA / 12.4KW
Duty cycle100%
ProcessesDC CO2/MAG, MMA, Arc Gouging
Dimensions684×320×580mm
Weight34kg
